TY266/GRP01

Description

D.C. NEUTRAL REED FOLLOWER RELAY
The TY266/GRP01 is a 6F 6B DC Neutral Reed Follower designed for use in the reed receiver amplifier circuit on RR 2002 and RR 2003 units. It is a direct replacement for GEC’s ZS2411. Of compact modular plug-in design it has non-weld contacts and is equipped with a safety interlocking system (pin code) for insertion into mating plugboards.

Specifications

• Catalogue Number: 0085/001970
• Network Rail Certification No: PA05/04802
• Q Reference: QT2R
• Pin Code: 0133
• BRB Specification: ZS2411
• Complete Contact Arrangement: 6F3B
• Nominal Voltage/Current: 12V d.c.
• Dimensions (mm): 120 x 58 x 180mm
• Weight: 1.24kg
